High Wear Resistance of Floating Fender

Short Description:

Characteristics of polyurea elastomer:：

1. Polyurea elastomer is a new synthetic material that combines the strength of plastic and the elasticity of rubber.
2. It has excellent wear resistance, up to 3-5 times that of natural glue.
3. This material has great oil resistance, about 4 times that of butadiene rubber.
4. With high mechanical strength, it can withstand tears and heavy loads, surpassing ordinary rubber.
5. It has outstanding resistance to acid, alkali, low temperatures, and solvents.
6. Polyurea elastomer has a strong bonding capacity with metal frame plates.
7. Its wide hardness range, from A10 to A100, allows for customizable elasticity.

Send email to us

Product Detail

Product Tags

Foam filled fender component

Polyurethane elastomer, EVA foaming, steel pipe and flange four parts.

Foam filled fender best features

1. Our product has high floating performance that is not affected by the tide.
2. We offer a variety of bright colors to meet customer requirements.
3. Our product does not require gas to be added during use, and is resistant to scratching, puncture, and friction. It is also resistant to sea water, acid, and alkali, with a service life of 25-30 years. It is safe to use and maintenance-free.
4. Despite having a solid core, our product is lightweight and easy to install and move around.
5. Our product provides a noticeable increase in reaction force and high energy absorption when compressed up to 60%.

Common dimensions and properties of foam-filled fenders

SIZE		Compression deformation 60%
Diameter（mm）	Length (mm)	Reactionforce-kn	Energyabsorb kn-m
300	500	38	1.8
400	800	56	2.6
500	1000	71	3.8
600	1000	95	5
700	1500	150	24.5
1000	1500	205	49
1000	2000	274	64
1200	2000	337	93
1200	2400	405	129
1350	2500	514	172
1500	3000	624	216
1700	3000	807	260
2000	3500	990	456
2000	4000	1163	652
2500	4000	1472	1044
2500	5000	1609	1228
3000	5000	2050	1412
3000	6000	2460	1695
3300	6500	2665	1836
