High Strength Boat Lift Airbags Special for Ship Maintenance

Short Description:

Main business of the company

Company’s long-term commitment to Boat Lift Airbags, Marine salvage airbags, yokohama pneumatic fender, Marine pneumatic fender, inflatable rubber fender, pneumatic rubber fender, yokohama fender, research and development, production and sales of the pneumatic fender in yokohama, using natural rubber and styrene butadiene rubber, polybutadience rubber, such as synthetic rubber, rubber hard, more abrasion resistance and toughness, product use high quality materials and special explosion-proof technology, sightseeing along the outside, good wear resistance, aging resistance, air tightness, high intensity, long service life, high quality, and through the ISO17357 and ISO9001: 2008 international quality management system certification and CCS, ABS, BV, DNV, GL, LR and other product quality certification, and for the national large construction enterprises and wharf protection to provide products and services.

Pneumatic rubber fender is also called Yokohaine fender, inflatable rubber fender, Marine pneumatic fender and Marine fender.

Send email to us

Product Detail

Product Tags

Marine airbag preparation before use

1. Clear and clean the sharp objects such as iron on the berth to avoid scratching the Marine airbag and causing unnecessary losses.
2. Place the Marine airbags at the bottom of the ship at a predetermined distance and inflate it. Obact the rising state of the ship and the pressure of the air bag at any time.
3. After inflating all Marine airbags, check the state of the air bags again, check whether the ship is balanced, and check whether the berth is clean and tidy.
4. The most important thing for the ship to use the air bag to launch is the stern first, and the stern first introduces the water surface; If it had gone the other way, the propeller at the back of the boat would have scraped the air bag, causing a safety accident.

Marine airbags performance

Diameter	Layer	Working pressure	Working height	Guaranteed bearing capacity per unit length(T/M）
D=1.0m	6-8	0.18MPa-0.22MPa	0.5m-0.8m	≥13.7
D=1.2m	6-8	0.17MPa-0.2MPa	0.6m-1.0m	≥16.34
D=1.5m	6-8	0.16Mpa-0.18MPa	0.7m-1.2m	≥18
D=1.8m	6-10	0.15MPa-0.18MPa	0.7m-1.5m	≥20
D=2.0m	8-12	0.17MPa-0.2MPa	0.9m-1.7m	≥21.6
D=2.5m	8-12	0.16MPa-0.19MPa	1.0m-2.0m	≥23

Dimensions and specifications of Marine airbags

Size	Diameter	1.0m，1.2m，1.5m，1.8m，2.0m，2.5m，2.8m，3.0m
	Effective Length	8m, 10m，12m，15m，16m, 18m，20m，22m，24m,Etc.
Layer	4layer，5layer，6layer，8layer，10layer，12layer
Remark:	According to different launching requirements, different ship types and different ship weights, the slope ratio of berth is different, and the size of Marine airbag is different. If there are special requirements, can be customized.
